AURATON 8D PRO RTH

A wireless strip to control floor heating actuators, intended for installation in electrical cabinets. AURATON 8D PRO RTH works with wireless temperature controllers. It enables simultaneous control of the operation of the central heating pump and of the heating device. Equipped with unique feature – link two or more strips together and control all actuators, pumps and heating device like it was only one controller.

Properties

  • 8 heating zones.
  • Each zone can be connected to up to 3 AURATON TE 230 or AURATON TE 230PRO actuators.
  • Easy to use and install on a DIN rail.
  • Control of a central heating circulation pump.
  • Control of a central heating boiler via a relay with potential-free contacts.
  • Intended for cooperation with wireless AURATON temperature controllers.
  • In order to facilitate installation, the terminals are fitted with detachable terminals.

Gallery

Technical data

Montage place DIN rail
Power supply 230V AC 50Hz
Number of controlled heating zones 8
Maximum number that can be connected 8 wireless AURATON thermostats
Load capacity of the 230V head control outputs 30 W per zone (up to 3 AURATON actuators)
Load capacity of the 230V CH pump output 230V AC, 2 A
Load capacity of transmitter 200W
Indication of operation status LEDs
Radio frequency 868MHz
Range of operation In a building – approx. 30 m;
in open field – up to 300 m
Radio frequency 868MHz
